Eaton UPS 7.2 kW 8000 Va .RS-232 USB 3U 19″ Network Card 2xLegs Stand 9PX8KPM
SKU: 9SIAA4THJW664396.799.755₫
EatonUPS7.2 kW8000 VARS-2329PX8KPM
Description
Eaton UPS 7.2 kW 8 kVA .RS-232 USB 3U 19″ Network Card 2xLegs Stand 9PX8KPM
Condition: Refurbished
Compeve SKU: 264900106413
Condition: Refurbished
Compeve SKU: 264900106413
Specification:
Product Name – Eaton 9PX Power Module
Catalog Number – 9PX8KPM
Upc – 743172039255
Product Length/depth – 23.5 In
Product Height – 5.1 In
Product Width – 17.3 In
Product Weight – 47 Lb
COMPLIANCES:
Ce Marked
Fcc Part 15
Cispr22 Class A / Fcc Part 15 Class A
CERTIFICATIONS:
Iec 62040-2:2006 Cat C2
Nom
Culus Listed
Energy Star Certified
Battery Management – ABM technology (3-stage charging extends battery service life by 50% and provides advance warning for battery replacement)
Output Waveform – True sine wave
VA Rating – 8 kVA
Max Number Of Battery Packs – 12 (supercharger required for more than 6 EBM)
Wattage – 7.2 kW
Output Power Factor – 0.9
Form Factor – Rack/tower
Receptacle – Hardwired
Includes Network Card – Yes
Input Connection – Hardwired
Noise Level – less 45 dB at 1 meter
Software Compatibility – Intelligent Power Software Suite
User Interface – Graphical display, 5-button programmable menu
Battery Type – Sealed, lead-acid
Efficiency – 94%
Rack Size – 3U
Voltage – 208 V
Temperature Range – 0° to 40°C (32° to 104°F)
Ethernet Interface – Yes
Protocol – SNMP
COMMUNICATION
Web/SNMP in MiniSlot expansion port + 1 USB port + 1 serial RS232 port + 1 mini-terminal block for remote ON/OFF + 1 mini-terminal block for remote power off + 1 mini-terminal block for output relay Communication slot
Relative Humidity – 0-95% non-condensing
Special Features – Network Card-MS included
Color – Black/silver
Rack Mounting Kit – Yes
Extended Battery Capability – Yes
Output Voltage Range – ±1% steady-state
Topology – Online/Double-conversion
Btu Rating – Online: 1760, Battery: 2375
Output Frequency – 50/60 Hz
TYPE – Accessory
Output Nominal Voltage – 208V default (200/208/220/230/240/250V)
Input Nominal Voltage – 208V default (200/208/220/230/240/250V)
INPUT POWER FACTOR – Greater 0.99 typical
Expansion Slots – (1) Mini-Slot (MS) expansion port with Network-MS Web/SNMP card included
Input Frequency Range – 60 Hz: 50-70 Hz, 50 Hz: 40-60 Hz
Internal Bypass – Yes
Altitude – less 1000m for nominal power, 10% power degrading every 1000m (up to 3000m)
Compeve DTP#: mrk001
Learn more about the Detailed Specifications
| VA | 8000 VA |
|---|
| Date First Available | January 26, 2022 |
|---|
