APC Smart-UPS 1.98 kW 2200 VA – with APC SmartConnect P/N: SMT2200C

Trusted Protection. Simplified Management. Perfect for distributed IT. Protect servers, switches, networking devices, and point-of-sale equipment with the APC Smart-UPS 2200VA. APC Smart-UPS provide backup battery power during power outages and continuously safeguard devices from fluctuating power conditions and surges. With premium protection and simplified management, the 2200VA UPS ensures consistent and reliable connectivity at the most critical moments. Consistent and Reliable Connectivity With 10 outlets and 1 switched outlet group, this server and network UPS provides uninterrupted battery power to connected electronics. With sine wave output when on battery, this tower UPS offers the highest degree of compatibility with PFC servers and sensitive electronics.

Monitoring Flexibility; EcoStruxure Ready Monitor your Smart-UPS from anywhere at any time via two options; cloud-based secure web portal with automated, customizable alerts regarding the health of your UPS or EcoStruxure IT software and services for larger scale or highly distributed IT infrastructures. Connect to either monitoring software using the Port on the back of the device. Alternate Monitoring and Management Options Use the intuitive LCD interface and PowerChute software to configure settings and monitor usage. A SmartSlot in the back of the UPS offers the option to add a Network Management Card (NMC) to remotely manage the UPS over the network (NMC sold separately).

Audible alarms also provide notification of changing utility power and UPS conditions. High Efficiency This 1920 watt UPS offers a green mode to ensure you are operating at the highest level of efficiency while its smart battery management maximizes performance. Automatic Voltage Regulation (AVR) adjusts voltages ensuring reliable power while preserving battery life. Additional Specifications One switchable outlet group is included for individual load management. Predictive battery management provides an estimated date of when battery replacement is recommended. Package Contains UPS, Smart UPS signalling RS-232 cable, USB cable. Tech Specs Specifications are provided by the manufacturer.

HeaderManufacturer: APC
Brand: APC
ProductLine: APC
Smart-UPSModel: SMT2200C
Bundledwith: APC SmartConnect
CountryKits: Canada, United
StatesPackagedQuantity: 1
GeneralSubcategory: UPS
ProductType: UPS Networking
RemoteManagementInterface: RS-232,
USBExpansionSlotsExpansionSlots: 1 (total) / 1 (free) x SmartSlot
InterfaceProvidedInterfaces: 1 x USB, 1 x EPO (emergency power off), 1 x management (RS-232)
CableDetailsCablesIncluded: USB cable – external, Serial cable – external, Power cable 6 ft
SoftwareType: Drivers & Utilities Power Device
FormFactor: External
UPSTechnology: Line interactive
VoltageProvided: AC 110/120/127 volt
VoltageProvidedMargin: ± 5%
FrequencyProvided: 50/60 hertz
FrequencyProvidedMargin: ± 3% UPS
OutputWaveform: Sinewave
PowerProvided: 1.98 kilograms per millimetere
PowerCapacity(VA): 2200 volt ampere per kilogram
VoltageRequired: AC 110/120/127 volt
InputVoltageRange: AC 82 – 144 V
InputVoltageRange(Adjustable): AC 75 – 154 V
FrequencyRequired: 50/60 hertz
FrequencyRequiredMargin: ± 3%
InputConnectorType: Power NEMA 5-20P
InputConnectorQty: 1 Output
ConnectorType: Power NEMA 5-15, Power NEMA 5-20
OutputConnectorQty: 10
SwitchoverTime: 6 millisecond
SurgeSuppression: Yes
SurgeEnergyRating: 530 joules
CircuitProtection: Circuit breaker
PowerDeviceFeatures: Automatic Voltage Regulation (AVR), Energy meter, LCD display, Cold-start function, Predicitive failure notification, Audible alarm, Automatic self-test, Hot-swappable batteries, Emergency power off Power Output Connectors Details
PowerOutputConnectorsDetails: 8 x power NEMA 5-15, 2 x power NEMA 5-20
BatteryRunTime(Up To): 10.1 minute (time unit)
LoadType: At full load
RechargeTime: 3 Hours Lead Acid
BatteryFeatures: Leak-proof, Maintenance free, Sealed Run Time Details Run Time (Up To): 113 min at 300 Watts, 339 min at 100 Watts, 51.3 min at 600 Watts, 63 min at 500 Watts, 35.8 min at 800 Watts, 16.7 min at 1400 Watts, 30.8 min at 900 Watts, 11.2 min at 1800 Watts, 26.8 min at 1000 Watts, 13.6 min at 1600 Watts, 20.8 min at 1200 Watts, 82 min at 400 Watts, 10.1 min at full load, 28.3 min at half load, 587 min at 50 Watts, 175 min at 200 Watts, 42.4 min at 700 Watts UPS
BatteriesQty: 1
BatteryTechnology: Lead acid
MiscellaneousColor: Black
ColorCategory: Black
CompliantStandards: FCC Part 15 A, UL 1778, CSA, UL 1449 Environmental
StandardsENERGYSTAR: Yes Dimensions &
WeightWidth: 7.7 inch
Depth: 21.5 inch
Height: 17 inch
Weight: 112.24 lbs Dimensions &
Weight(Shipping)ShippingWidth: 15 inch
ShippingDepth: 30 inch
ShippingHeight: 22 inch
ShippingWeight: 134.28 lbs
EnvironmentalParametersMinOperatingTemperature: 32 degree Fahrenheit
MaxOperatingTemperature: 104 degree Fahrenheit
HumidityRangeOperating: 0 – 95%
SoundEmission: 45 dBA
