HPE ProLiant DL20 Gen9, 1x 3.0GHz 4-Core CPU, 16GB DDR4 RAM, Smart Array P440 2GB, 4x 1.92TB SSD, 2x 1GbE, HPE iLO

The dense and compact HPE ProLiant DL20 Gen9 Server is an entry level server which is powered by Intel Pentium, Core i3 and E3-1200 v5/v6 processors and supports up to 64GB DDR4 2400MHz ECC Unbuffered memory. The 1U form factor build is equipped with 4x hot-swappable 2.5” SAS/SATA drive bays, supports 1x low profile PCIe expansion card and comes with the fixed 290W 80Plus Silver certified power supply.
Interfaces:

• Video:

• 1x Rear Video Connector
• USB:

• 5 USB ports (standard):

1. Front: 2x USB 2.0
2. Rear: 2x USB 3.0
3. Internal: 1x USB 3.0

• Micro SD Slot:

• 1x Micro SD
• LOM Network Ports

• 2x 1GbE ports

5 USB ports (standard)

1. Front: 2x USB 2.0
2. Rear: 2x USB 3.0
3. Internal: 1x USB 3.0

System: HPE ProLiant DL20 Gen9

Processor: Xeon E3-1220 v5 3.0GHz Quad Core Processor

Memory: 16GB (2x 8GB) DDR4 Memory

Storage Controller: HP Smart Array P440 SAS/SATA Controller with 2GB Battery Backed Cache, (Supports RAID 0,1,10,5,50,6,60,10 ADM-Advanced Data Mirroring)

Hard Drive: 4x 1.92TB 6Gbps SATA SSD

Integrated Network: Integrated HPE Ethernet 1Gb 2-port 332i

Management: HPE iLO

Power Supply: 1x 290W Power Supply

Rails: Does Not Include Rails
