HPE ProLiant DL20 Gen10 Performance Xeon E-2224 3.4 GHz RM RAM 16GB P17079-B21

Header
Manufacturer :HPE Smart Buy Express
Brand :HPE
Product Line :HPE ProLiant
Model :DL20 Gen10 Performance
Packaged Quantity :1

System
Type :Server
Hard Drive Capacity :0 GB

Chassis
Form Factor :Rack-mountable
Manufacturer Form Factor :Rack-mountable
Server Swappable Drive Form Factor :3.5″
Server Swappable Drive Form Factor (metric) :8.9 cm
Server Swappable Drive Interface :SATA

Processor
Type :Xeon
Number of Cores :Quad-Core
Processor Number :E-2224
Installed Qty :1
Max Supported Qty :1
Server Scalability :1-way
Upgradability :Upgradable
Manufacturer :Intel
Clock Speed :3.4 GHZ
Max Turbo Speed :4.6 GHZ

Mainboard
Chipset Type :Intel C242
Cache Memory
Per Processor Size :8 megabyte, 8 megabyte, 8 megabyte, 8 megabyte
Installed Size :8 megabyte, 8 megabyte, 8 megabyte, 8 megabyte

RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :16 GB, 16 GB, 16 GB, 16 GB
Max Supported Size :64 GB, 64 GB, 64 GB, 64 GB
Data Integrity Check :ECC
Slots Qty :4
Memory Speed :2666 megahertz
Rated Memory Speed :2666 megahertz
Memory Specification Compliance :PC4-21333
Features :Unbuffered

Storage Controller
Type :RAID
Interface Type :Serial ATA-600
Storage Controller Name :HPE Smart Array S100i SR Software RAID
Channel Qty :4
Installed Qty :1
RAID Level :RAID 10, RAID 0, RAID 1, RAID 5
Storage Controller (2nd)
Type :None
Hard Drive
Type :No HDD

Drive Type :No optical drive
Type :None

Storage Removable
Type :None

Display
Type :None.

Video Output
Graphics Processor :Matrox G200
Graphics Processor Series :Matrox G200
Video Interfaces :VGA

Networking
Ethernet Controller(s) :HPE 332i
Remote Management Controller :Integrated Lights-Out 4
Interface (Bus) Type :PCI Express x2
Data Link Protocol :Gigabit Ethernet, Ethernet, Fast Ethernet
Ethernet Ports :2 x Gigabit Ethernet
Features :PXE support, Wake on LAN (WoL)
Compliant Standards :IEEE 802.3ab, IEEE 802.3, IEEE 802.3u

Expansion Bays
Bays :1 (total) / 1 (free) x external 5.25″, 2 (total) / 2 (free) x internal 3.5″ LFF

Expansion Slots
Slots :1 (total) / 1 (free) x PCIe 3.0 x16 – full-length, full-height (x16 mode), 1 (total) / 1 (free) x PCIe 3.0 x8 – low-profile (x8 mode)

Interface Provided
Interfaces :5 x USB 3.0 (2 front, 2 rear, 1 internal), 1 x LAN (Gigabit Ethernet) / HP iLO, 1 x LAN (GigabitEthernet), 1 x VGA

Power Device
Type :Power supply
Installed Qty :1
Power Provided :290 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz

Miscellaneous
Color Category :Black
Height (Rack Units) :1
Compliant Standards :ASHRAE Class A4, UEFI, ASHRAE Class A3, Redfish API, ACPI 6.1, AES, FIPS 140-2, TLSv1.2

Dimensions & Weight
Width :17.1 inch
Depth :15 inch
Height :1.7 inch
Weight :17.37 lbs
