SUPERMICRO MBD-X8DTU-F-O Proprietary Server Motherboard Dual LGA 1366 Intel 5520 DDR3 1333/1066/800
SKU: 9SIA17PJBV780912.253.605₫
Dual LGA 1366
Intel 5520
12 x 240pin
Description
var ccs_cc_args = ccs_cc_args || []; ccs_cc_args.push([‘mf’,’Super Micro’]); ccs_cc_args.push([‘pn’,’MBDX8DTUFO’]); ccs_cc_args.push([‘upcean’, ”]); ccs_cc_args.push([‘lang’, ‘en’]); ccs_cc_args.push([‘market’, ‘US’]); (function () { var o = ccs_cc_args; o.push([‘_SKey’, ‘1b1e8766’]); o.push([‘_ZoneId’, ‘faa3fafd5b’]); var sc = document.createElement(‘script’); sc.type = ‘text/javascript’; sc.async = true; sc.src = (‘https:’ == document.location.protocol ? ‘https://’ : ‘//’) + ‘cdn.cnetcontent.com/jsc/h.js’; var n = document.getElementsByTagName(‘script’)[0]; n.parentNode.insertBefore(sc, n); })();
This X8DTU-F Server Board is designed with the utmost attention to detail to provide the highest standards in quality and performance. X8DTU-F supports the Intel 5500 Series processors, the first dual-processing platform that supports the Intel QuickPath Interconnect (QPI) Technology, providing the next generation point-to-point system interface to replace the current Front Side Bus.
Learn more about the Supermicro MBD-X8DTU-F-O
| Brand | SUPERMICRO |
|---|---|
| Model | MBD-X8DTU-F-O |
| CPU Socket Type | Dual LGA 1366 |
|---|---|
| CPU Type | Dual Intel Xeon 5600/5500 series |
| QPI | Up to 6.4 GT/s |
| North Bridge | Intel 5520 |
|---|---|
| South Bridge | ICH10R + IOH-36D |
| Number of DDR3 Slots | 12 x 240pin |
|---|---|
| DDR3 Standard | DDR3 1333/1066/800 |
| Maximum Memory Supported | 192GB |
| ECC Supported | Yes |
| Registered | Yes |
| PCI Express 2.0 x16 | Left Side: 1 (x16) PCI-E 2.0 + 1 UIO or 1 (x16) PCI-E 2.0 |
|---|
| SATA | 6 x SATA 3.0Gb/s |
|---|---|
| SATA RAID | RAID 0, 1, 5, 10 support (Windows) RAID 0, 1, 10 support (Linux) |
| Onboard Video Chipset Onboard Video Chipset | Matrox G200eW |
|---|
| LAN Chipset | Intel 82576 |
|---|---|
| LAN Speed | 10/100/1000Mbps |
| Max LAN Speed | Dual 10/100/1000Mbps |
| PS/2 PS/2 | 2 |
|---|---|
| COM | 1 |
| Video Ports | D-Sub |
| USB 1.1/2.0 | 2 x USB 2.0 |
| Features | Integrated IPMI 2.0 with Dedicated LAN
CPU: Supports up to two Intel 64-bit Xeon processor(s) of the same type below: |
|---|---|
| Onboard USB | 2x USB on-board 4x USB internal headers |
| Form Factor | Proprietary |
|---|---|
| Dimensions (W x L) | 12.075″ x 13.05″ |
| Date First Available | November 18, 2022 |
|---|
