Supermicro MBD-X10SRA-B Server Motherboard
SKU: 09Z-01PF-000N313.743.405₫
LGA 2011-3
Intel C612
Description
The new Supermicro’s X10 UP Serverboards offer the latest Xeon E5-2600/1600 v3 technology solutions with the highest levels of performance in different form factors to meet various application needs. X10SRL-F, with 7x PCIe (up to 5x PCIe 3.0 x8) slots onboard, is the best choice to maximize your I/O intensive application demand. On the other hand, X10SRi-F offers the latest virtualization support at low cost. For customers who need multiple I/O solutions in a 1U chassis, X10SRW-F (up to 3x AOC) and X10SRG-F (up to 5x AOC) provide the ultimate solutions. Supermicro’s first UP Storage serverboard, X10SRH-CF/-CLN4F, brings the latest SAS3 (12Gb/s data rate) technology to the market with the best performance per dollar value.
Learn more about the Supermicro MBD-X10SRA-B
| Best Seller Ranking | #77 in Server Motherboards |
|---|
| Brand | SUPERMICRO |
|---|---|
| Model | MBD-X10SRA-B |
| CPU Socket Type | LGA 2011-3 |
|---|---|
| CPU Type | Supports: Intel Core i7 series Intel Xeon Processor E5-1600 v3 Intel Xeon Processor E5-1600 v4 Intel Xeon processor E5-2600 v3 Intel Xeon processor E5-2600 v4 |
| North Bridge | Intel C612 |
|---|
| Number of DDR4 Slots | 8 x 288-pin |
|---|---|
| DDR4 Standard | 2400 / 2133 / 1866 / 1600 MHz ECC DDR4 SDRAM 72-bit |
| Maximum Memory Supported | Up to 1TB ECC 3DS LRDIMM Up to 512GB ECC LRDIMM Up to 256GB ECC RDIMM Up to 128GB DDR4 ECC / non-ECC UDIMM (available with Core i7 only) |
| ECC Supported | Yes |
| PCI Express 3.0 x16 | 4 |
|---|---|
| Other Slots | 2 x PCI-E 2.0 x1 (in x4) slots |
| SATA | 10 x SATA 6.0Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Audio Chipset Audio Chipset | Realtek ALC1150 |
|---|---|
| Audio Channels Audio Channels | 7.1 Channels |
| Number of LAN | 2 x RJ45 Gigabit Ethernet LAN ports |
|---|---|
| LAN Chipset | Intel I210-AT |
| USB 3.0 USB 3.0 | 6 x USB 3.0 |
|---|
| Features | Single socket R3 (LGA 2011) supports Intel Xeon processor E5-2600 v4 / v3, E5-1600 v4 / v3, Core i7
Intel C612 chipset Up to 512GB ECC DDR4 2400 MHz LRDIMM or 128GB ECC / non-ECC UDIMM (available with Core i7 only); 8 x DIMM slots 4 x PCI-E 3.0 x16 (run at 16 / 16 / NA / 8 or 16 / 8 / 8 / 8), 2 X PCI-E 2.0 x1 (in x4) Intel i210-AT Dual port GbE LAN 10 x SATA3 (6 Gbps) 1 x COM, 1 x TPM 8 x USB 3.0 ports (6 rear + 2 via header) HD Audio 7.1 channel connector by Realtek ALC1150 |
|---|
| Date First Available | November 20, 2017 |
|---|
